Name: WRD5012 WRD5016 WRD5020 Radial Drilling Machines
Brand: Weiss Machinery
Rating: 5.0 (43 reviews)

Packaging & Delivery

Selling Units:	Bag/Bags

Supply Ability & Additional Information

Transportation: Others

Product Description

Specifications

Model No.	WRD5012	WRD5016	WRD5020
Item No.	10305501	10305502	10305503
Specifications：
Max. drilling capacity	Φ50 mm	Φ50 mm	Φ50 mm
Distance from spindle wis to column	350~1250 mm	350~1600 mm	350~2000 mm
Diameter of column	350 mm	350 mm	350 mm
Spindle taper	MT5	MT5	MT5
Spindle stoke	315 mm	315 mm	315 mm
Step of spindle speeds	16	16	16
Range of spindle speeds	25~2000 rpm	25~2000 rpm	25~2000 rpm
Step of spindle feeds	16	16	16
Range of spindle feeds	0.04~3.2 mm/rev.	0.04~3.2 mm/rev.	0.04~3.2 mm/rev.
Distance from spindle nose to base	350~1220 mm	350~1220 mm	350~1220 mm
Dimension of worktable	630 x 500 x 500 mm	630 x 500 x 500 mm	630 x 500 x 500 mm
Base size	2050 x 1000 x 200mm	2400 x 1000 x 200mm	2400 x 1000 x 200mm
Main Motor	4 kw	4 kw	4 kw
Overall size	2150 x 1060 x 2650 mm	2500 x 1060 x 2650 mm	2900 x 1060 x 2650 mm
Packing size	2400 x 1120 x 2520 mm	2600 x 1120 x 2600 mm	3000 x 1120 x 2600 mm
Net weight	3100 kg	3500 kg	3550 kg

Features&Details

Features:

With wide range of speed and feed, with manual, powerand fine feeds. The feed of machines are very easily engaged and disengaged at any time.
With safe and reliable feed safety machine, all parts easyoperation and change.
All controls centralized on the head stock easy operation and change. With rapid and accurate hydraulic preselection of speeds and feeds of spindle.
Main parts are made by machine center which with high precision and efficiency, ensuring reliability and high quality.
Integrating technology for casting parts is excellent, adopting casting equipment, ensuring high quality of materia for basic parts.
Spindle parts are made by special high quality steel heattreatment to be made by first class equipments, ensuring high strength and durability.
Main gears are machined by gear grinding, the machine ensuring high precision and Iow noise.
