WM630E/WM800E/WM850E/WM1000E/WM1200E HEAVY DUTY LATHE MACHINE

WM630E/WM800E/WM850E/WM1000E/WM1200E HEAVY DUTY LATHE MACHINE
Share:
Price
Get Latest Price
    • Min. Order: 1 Bag/Bags
    • Transportation: Others
    Share:
    Contact Now>
    Product Detail Description
    Product Attributes

    Model No.: WM630E/WM800E/WM850E/WM1000E/WM1200E Heavy Duty Lathe Machine

    Distance Between Centers: 1000mm 1500mm 2000mm 3000mm 4000mm 5000mm 6000mm 8000mm 10000mm 12000mm

    Packaging & Delivery
    Selling Units: Bag/Bags
    Supply Ability & Additional Information

    Transportation: Others

    Product Description
    Specifications

    Model No. WM630E/WM800E/WM850E/WM1000E/WM1200E
    ITEM NO. WM630E:10108000-10108009
    WM800E:10108020-10108029
    WM850E:10108040-10108049
    WM1000E:10108060-10108069
    WM1200E:10108080-10108089
    Specifications： Metric(mm) Imperial (in)
    Distance between centers 1000/1500/2000/3000/4000/5000/6000/8000/10000/12000mm
    1000/1500/2000/3000/4000/5000/6000/8000 mm (for WM1000, WM1200)
    Swing over bed 630/800/850/1000/1200 mm
    Swing over gap 800/1000/1050/1200/1400 mm
    Swing over cross slide 360/485/535/ 685/685 mm
    Width of bed 550 mm
    Spindle bore 105 mm/130 mm
    Spindle nose C-11 or D-11
    Spindle taper 1:20
    Range of spindle speeds 14-750 rpm / 18
    Range of cross feeds 0.024-12.15 mm/r 72 kinds
    Range of longitudinal feeds 0.048-24.3 mm/r 72 kinds
    Range of metric threads 1-240mm 54 kinds
    Range of inch threads 28-1 T.P.I 36 kinds
    Range of moduler threads 0.5-60 M.P 27 kinds
    Range of diametrical threads 30-1 D.P 27 kinds
    Rapid feed Longitudinal/Cross 4 m/min, 2 m/min.
    Top slide travel 240 mm
    Cross slide travel 420 mm
    Tailstock quill travel 205 mm
    Tailstock quill diameter 100 mm
    Tailstock quill taper MT6
    Main motor 11 kw
    Rapid feed motor 0.18 kw
    Coolant pump motor 0.09 kw
